Alcon CustomCornea
The LADARVision CustomCornea system for LASIK, by Alcon.
CustomCornea
CustomCornea is one of the most advanced LASIK procedures currently on the market. It differs from standard LASIK procedures because it is 1)fully customized to your eyes and 2)addresses higher order aberrations (more subtle vision problems) in your eyes that are harder to detect.
LADARWave WaveFront Device
The LADARWave creates a 3-D WaveFront map of each of your eyes by measuring the refracted light from a mapping laser. This WaveMap is used to both determine the course of surgery and to guide the laser through it. The WaveFront map is entirely unique to each of your eyes so the procedure is completely individualized.
LadarTracker
The LadarTracker takes measurements on the positioning of your eye over 4,000 times per second, making it the fastest tracking system on the market¹. Implementing a closed loop system, the tracker follows the eye at all times and can respond to any movement in 1ms².
Note: The tracker requires 7mm of pupil diameter to track effectively. This necessitates dilation².
Current Excimer Lasers
After the WaveFront map is matched to your eye's positioning, the cornea is precisely reshaped using a LADARVision Excimer Laser. Corneal tissue is removed according to the specific higher and lower order aberrations of your eye (See LASIK Surgery for more specific information on this part of the procedure). This process is guided by the LADARVision eye tracking device and tailored to the specific characteristics of our eye.The LADARVision 4000
Specifications
- Speed:
- Type/Size of beam: Gaussian small flying spot beam; 0.8mm
- Optical Zone (OZ): 5.5mm
- Treatment Zone (TZ): 7.5mm
Treatment Range
- Myopia: -8.00 D with astigmatism; -4.00 D without astigmatism
- Hyperopia: +5.00 D (with/without astigmatism
FDA Approvals
The LADARVision 6000
Features
- Greater range of treatment for hyperopia
- 50% faster ablation
- Flexible platform for increased treatment customization
Specifications
- Speed:
- Type/Size of beam: Small spot flying beam; 0.8mm
- Optical Zone (OZ): 6.5mm
- Treatment Zone (TZ): 9.0mm
Treatment Range
- Myopia: -8.00 D with astigmatism; -4.00 D without astigmatism
- Hyperopia: +5.00 D; -3.00 D with astigmatism
FDA Approvals
- 2006: Same as LADARVision 4000 but with improvements
